DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8

DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8

Name: DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8
Brand: SMTS Panels And Automation
Price: 16000.0 INR
Availability: InStock

16000.0 INR/Number

Get a Price/Quote

Product Details:

Thermal Conductivity 45 Calorie (IT)/second/centimeter/°C
Features Compact design, Snap-on mounting, Cost effective
Components Plug-in connector, Input circuitry
Power Supply 24V DC, 15-30V DC
Display Type LCDs
Operating Temperature 0C to 60C Celsius (oC)
Output N/A (Input module)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8 Price And Quantity

Minimum Order Quantity 1 Number
Price 16000.0 INR/Number

DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8 Product Specifications

Power Source External 24V DC supply
Interface Expansion bus for S7-200 PLC
Current Rating Input current per channel typically 5mA (at 24V DC)
IP Rating IP20
Phase single
Size Standard size for S7-200 expansion
Usage PLC Automation, Industrial Control
Sensors Specification Digital signal compatible
Input 8 channels DI (Digital Inputs)
Conductor copper
Warranty 1 year
Output N/A (Input module)
Cable Type copper
Response Time Typically <10 ms Seconds
Power Rating good
Operating Temperature 0C to 60C Celsius (oC)
Material plast
Rated Voltage 24 Volt (V)
Capacity 224V DC (15-30V)4V DC (15-30V) Milliliter (ML)
Display Type LCDs
Color Dark Grey
Power Supply 24V DC, 15-30V DC
Supply Voltage 24V DC (15-30V) Volt (v)
Application Compatible with Siemens S7-200 CN PLCs
Frequency otN specified for digital input modules Milihertz
Components Plug-in connector, Input circuitry
Usage & Applications general
Thickness Standard Siemens S7-200 module dimensions Millimeter (mm)
Product Type Digital Input Expansion Module
Function Digital Input Module for signal acquisition
Weight Approx. 150gApprox. 150g Grams (g)
Rated Current 1 Volt (v)
Thermal Conductivity 45 Calorie (IT)/second/centimeter/°C
Features Compact design, Snap-on mounting, Cost effective
Dimension (L*W*H) Typically 75 x 100 x 40 mm (estimate) Millimeter (mm)

Product Series Siemens S7-200 CN
Input Signal voltage range 15-30V DC
Input Type Sink/Source (configurable)
Model Number 6ES7221-1BF22-0XA8
Product Condition Brand New, Unused
Mounting Type DIN Rail Mount
Number of Inputs 8 Digital Inputs
E-Stand Version 06

DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8 Trade Information

Delivery Time 1 Seconds

Product Description

The EM 221 module provides a compact and economical method to expand the digital input capacity of an S7-200 CN base CPU without needing to upgrade to a larger controller. It enables the PLC to monitor up to 8 additional external 24 V DC binary signal devicessuch as limit switches, pushbuttons, photoelectric eyes, and proximity sensorsin industrial automation setups.

Flexible Input Configuration

This module supports both sink and source wiring for its eight digital inputs, providing convenient adaptability to various industrial control setups. Its versatile voltage range (15-30V DC) ensures reliable compatibility with a broad array of automation signal sources.

Easy Mounting and Integration

Engineered for DIN rail mounting, the 6ES7221-1BF22-0XA8 seamlessly expands your Siemens S7-200 CN PLC system. Its standardized size and straightforward plug-in connector streamline system setup and future expansions, saving valuable installation time.

Robust and Efficient Signal Acquisition

Operating stably between 0C to 60C with IP20 housing, this digital input module is tailored for industrial environments. Fast response time and dependable input detection empower precise control for automation processes. Its durable, compact design ensures efficient use of space and long-lasting performance.

FAQ's of DIGITAL INTPUT MODULE 6ES7221-1BF22-0XA8:

Q: How do I install the DIGITAL INPUT MODULE 6ES7221-1BF22-0XA8?

A: To install the 6ES7221-1BF22-0XA8 module, simply snap it onto a standard DIN rail and connect it to the S7-200 CN PLC expansion bus using the provided plug-in connectors. Ensure external 24V DC power is supplied and wire the input channels according to your application's sink/source requirements.

Q: What types of signals can this module acquire, and how many inputs does it support?

A: The module can acquire digital signals within a voltage range of 15-30V DC, supporting up to 8 independent digital input channels. It is compatible with most standard digital sensors and switches used in industrial automation.

Q: When should I use the 6ES7221-1BF22-0XA8 in my automation project?

A: Use this digital input module when you need to expand the number of digital inputs on your Siemens S7-200 CN PLC system. It is ideal for applications where reliable signal acquisition and compact design are essential, such as industrial control and monitoring.

Q: Where is the 6ES7221-1BF22-0XA8 best suited for installation?

A: This module is best suited for use inside control panels, on DIN rails, in environments where a 0C to 60C temperature range and an IP20 protection rating are suitable. Its compact construction makes it an excellent fit for industrial automation cabinets with limited space.

Q: What is the process for configuring the input type (sink/source)?

A: To configure each input as either sink or source, refer to the wiring diagram in the product manual. Connect your field wiring accordingly, as each input channel is configurable based on how you wire the field device's positive and negative terminals.

Q: How does this module benefit my industrial automation system?

A: It provides a cost-effective means to increase digital input capacity while maintaining seamless communication with Siemens S7-200 CN PLCs. Its reliability, flexible wiring options, and rapid response enhance the overall efficiency and control stability of your automation solution.
